We are one of the leading distributor and supplier of Insulating Varnishesh
Impregnating Varnishes
We provide our customer with premium quality impregnating varnishes which are used for
impregnation of high speed motor armatures. In addition, it is also used for drives in chemical
industry and hand tools etc. Known worldwide for their excellent resistance to centrifugal forces. These have the following specifications:
| Product Designation | Chemical Base | Thinner | Viscosity at 23°C by DIN 53211/ Cup 4 (s) | Curing Cycle (,..°C/ ...h) | Suitable for Thermal Class | Distinctive Properties | Suggested Applications |
|---|---|---|---|---|---|---|---|
| Elmo 65 E/R | Alkyd phenolic | 205 | 40-60 | 130/8 | 130 (B) | Excellent resistance to centrifugal forces | Impregnation of high speed motor armatures, drives in chemical industry, hand tools, etc. |
| Elmo B 92 | Alkyd | 234 | 40-60 | 120/4 | 130 (B) | Flexible cured film. Short curing schedule | Impregnation of fan stalors |
| Elmo B 95 | Alkyd phenolic | 205 | 40-60 | 130/6 | 130(B) | Short curing schedule | Impregnation of motor stators, transformers, etc. |
| Elmoglas V 155 | Polyurethane | 218 | 45-65 | 140/14 | 130(B) | Resistant to refrigerant R11 SR22 | Impregnation of hermetic motor stalors, binder varnish for glass fiber tapes & sleeves. |
| Elmotherm F 50 | Isophlhalic alkyd | 205 | 50-70 | 120/12 | 155 (F) | Excellent dielectric properties under moist condition, good bond and adhesive strength | Impregnation of motor stators, rotors, generators, Aux. Traction motors etc. |
